Eigenschaften

Technische Daten

Applicable Industries: Farms

Number of Rows: 2, 3, 4, 5, 6, 8

Showroom Location: Zimbabwe

Condition: New

Type: Debont 1805

Application: no-till application

Use: seeding

Weight: 2900 KG

Dimension(L*W*H): 400*600*174 (cm)

Warranty: 1 Year

Key Selling Points: excellent seed placement

Marketing Type: New Product 2020

Machinery Test Report: Provided

Video outgoing-inspection: Provided

Warranty of core components: 1 Year

Core Components: opener, seed meter, press wheel, seed tank

Seed Feed: Clip/Vacuum Suction

Working Efficiency(Ha/h): 2.4-4.4

Tractor PTO Requirement (Hp): 90-120

Seeding Depth (mm): 30-80, 10 levels

Fertilizer Depth (mm): 60-130

Seed Tank Capacity(L): 35*2-35*8

Fertilizer Tank Capacity(L): 270*1-270*4

Openers: 2*360mm diameter

Working Speed(Km/h): 6-8

Min/Max Spacing (cm): 42-70

Grundinformation

Zahlung und Versand AGB

Packaging Details: container

Produkt-Beschreibung

Different from other manufacturers of seeder, Debont do not produce a lot of types of seeder. We possess unique advantage in no till seeders.

In recent years, as the strong support of Chinese government for the protection of soil and environment, the conservation tillage has been developed rapidly in the northeast of China, and Debont has become the most reliable brand among Chinese farmers, based on our deep study of the structure of several world leading no till brands, like Kuhn, Maschio, etc., and the development of our patented technology. Nowadays, Debont has been exported to more than 10 countries and been appraised by more and more foreign users. For more details, please be so kind to have a view of the presentation below:

Products Description

From 2 rows to 8 rows, which are designed for no-till applications, but also can quickly adjust to conventional tillage conditions. Only the 1205 (2-row) is the model of tractor-trailed, and the other models can be used as tractor-mounted

(3 points) and tractor-trailed, which can not only be used as no-till seeder on field with heavy residue(tractor-trailed), but also be used on cultivated field (tractor mounted). One machine for two occasions, the innovative feature of Debont no till seeder.

Operate in HIGH-residue condition + Control HIGH Precision of depth=HIGH efficiency and performance

Wonderful Performance of Debont in Lishu

The weight and openers are two key factors to make the seeder to realize the wonderful performance in high-residue fields. Debont seeder is the only seeder that can operate in the test field of Lishu District of Jilin Province, northeast of China. To develop the no till application and protect soil, the Agricultural University of China establishes the test field in Lishu. In the exceptional high-residue condition, only Debont seeder can operate on the field. The wonderful germination was praised by the President of China, Xi Jinping when he visited the field in July of 2019.

Structure of Debont No Till Seeder

The bottom of Debont seeder is composed with fertilizer opener, rotary coulter, ribbed disc, seed opener, profiling wheel, and press wheel. ensuring the precise depth control and even germination on uneven terrain. The seeder can open slit in soil, fertilize on base, press seed bed, drop in seed, close seed trench, and manage residue once a time. The working speed can reach 6-8 km/h, and the working efficiency reach 4 hectares per hour (8 rows seeder).

Equipped with double disc or single disc fertilizer opener with the size larger than othan brands, which has good passing capability and lie the fertilizer deeply.

Relying on gravity and spring, the ripple discs and rotary coulters loosen soil,open ditch and cut stubble.

The V-shaped hollow rubber wheel type soil covering roller is adopted to the press wheels to realize the extrusion of soil covering and realize a wonderful moisture conservation. The angle and pressure can be adjusted easily by the two handles.

The main beam, which adopts180mm thick steel, and the auxiliary beam, which adopts 120mm thick steel, are welded and fixed with side plates. And the reinforced traction beam is fixed on the main beam and the auxiliary beam.

The muti-functional intelligent monitor is used to monitor and display the monitoring data in real time, such as operation speed, sowing conditions, number of seeds, operation area, etc.

The fine-tuning device of fertilization amount is adopted to accurately adjust the fertilizer amount, realizing scientific fertilization.

The synchronous profiling structure is adopted to the seeding process, and the profiling wheel is mounted on both sides of the seeding ditcher to ensure the consistency of seeding depth.

Double side ground wheel synchronous transmission structure is adopted, which makes the transmission more reliable and the placement of seeds more precise.

The industry-leading seeding meter of clip finger or vacuum suction with brand Precision is equipped on Debont seeder. If you have a few types of seed to sow, the type of clip finger will be a better choice for a less cost and easier maintenance, and the rate of missed seeding can be lower than 3%. If you have several types of seed to sow, the type of vacuum suction will be better, and the rate of missed seeding can be lower than 1%. The following seeds are especially suitable to be sowed with Debont no till seeder:

Debont owns a advanced assembly line of seeder in Jiamusi, located in the northeast of China, where has the largest no till field of China.

Worldwide Applications

The Debont seeder was appraied by the President of Zambia.

Product Paramenters

	1205	1305	1405	1505	1605	1805
Seed Feed	Finger Clip/ Vacuum Suction	Finger Clip/ Vacuum Suction	Finger Clip/ Vacuum Suction	Finger Clip/ Vacuum Suction	Finger Clip/ Vacuum Suction	Finger Clip
Rows	2	3	4	5	6	8
Width/Height (mm)	31001880 1570	40002560 1740	40003500 1740	40004580 1740	40005100 1740	400060001740
Wight(kg）	1180	1870	2090	2830	3050	2900
Working Efficiency	0.6-1.1(Ha/h)	0.9-1.7(Ha/h)	1.3-2.4(Ha/h)	1.5-2.7(Ha/h)	1.8-3.2(Ha/h)	2.4-4.4(Ha/h)
Tractor PTO Requirement(Hp)	35-50 trailed	40-70 trailed or mounted	55-80 trailed or mounted	70-90 trailed or mounted	80-90 trailed or mounted	90-120 trailed or mounted
Seed Tank Capacity(L)	35*2	35*3	35*4	35*5	35*6	35*8
Fertilizer Capacity(L)	270+ 23*2	270+ 23*3	2702 +234	2703 +235	2703 +236	2704 +238

Openers

2*360mm diameters

Ribbed Discs

2*390 mm diameters

Profiling Wheel

2*400 mm diameters

V Shape Press Wheel

2*230mm diameters

Min/Max Row Spacing （cm)

42-70

Min Plant Spacing (cm)

Workding Speed（Km/h)

6-8

Seeding Depth (mm)

30-80, 10 levels

Fertilizer Depth (mm)

60-130

Company Profile

Invested by Jinan Jinpu New Energy, Agrecommerce Ltd. is the co-productive and e-commerce marketing partner of Debont Crop., the leading agricultural machinery manufacturer in China. We are aimed at equipping your farm with quality and cost-effectiveness and providing one-stop service for the cross-border trade of agricultural equipment and products. Agrecommerce owns professional R&D, manufacturing, marketing, and technical service teams and three production bases, specialized in irrigation equipment, seeders, and drying & storage machinery respectively. Based on our own website and online store on Alibaba, we are promoting agricultural equipment with brand of Debont. Agrecommerce and Debont are committed to delivering high-quality and innovative agricultural equipment and comprehensive solutions to help the growth of our customers worldwide, and to realize the maximum return of investment.

Certifications

FAQ

1.Debont no-till seeder can be used in conventional condition? Yes. Except the 1205 model, all the other models can be mounted on tractor and be used as tradicional precision seeder. The only issue that has to be paid attention is the PTO requirement, which has been shown on our parameter table.

2.Which type of seed can be sowed by Debont no till seeder? Corn, soybean, cotton, and other seeds that we have shown on this page. If you have question about which type of seed can be sowed by Debont no till seeder, please do not hesitate to contact with us.

3. Can I only purchase one seeder? Yes, you can. However, we suggest that you purchase several seeders to fill one container at least, considering the transport cost.
